A-135-2V Mini Quad VCA/Mixer Vintage Edition

Description

Doepfer A-135-2V Mini Quad VCA/Mixer Vintage Edition: Classic Aesthetics with Modular Power

The A-135-2V is the vintage-styled version of Doepfer’s Mini Quad VCA/Mixer, featuring four independent VCAs with both manual and CV control. Designed for flexibility in audio and CV mixing, the module offers individual outputs as well as a summed mix output. Its elegant black panel with white printing adds a timeless character to any Eurorack setup.

Key Features:

• Four VCAs with dedicated CV and audio inputs

• Manual and CV-controlled level adjustment

• Sum output for mixing all channels

• Supports both audio and control voltages

• Vintage Edition: black front panel with white print

Technical Specifications:

• Width: 8 HP

• Power Consumption: approx. +60 mA / -60 mA

• Inputs: 4 x audio, 4 x CV

• Outputs: 4 x individual, 1 x mix

• Color: Black (Vintage Edition)

Ideal for users seeking classic design and efficient signal control.
